12 CBM Liquid Chemical Tank Truck

BRIEF

Heavy duty Chemical transport tanker truck is also called chemical liquid tanker truck, is used for transport acid, alkali, salt, organic solvents and other corrosive and dangerous liquids, such as phosphorus, asphalt, hydrochloric acid, caustic soda, coal tar, concentrated sulfuric acid, alcohol, hydrogen peroxide, toluene, acetic acid, hydrofluoric acid, nitric acid, ammonia etc.

● Reliability. Global ownership is over 4 million units, adhering to the Cummins B series engine excellent reliability. The advanced design, the components is about 40% less than other similar engines, engine failure rate is much lower than other similar product.

● Low fuel consumption. Adopt imported high pressure common rail fuel system, injection pressure is up to 1800BAR, higher precision injection and full fuel atomization and more to insure lower fuel consumption.

● High working efficiency. Low engine speed, high torque, wide range of high torque, fast acceleration, easy climbing, high loading.

STANDARD FEATURES

● Loading Capacity 12000liters

● Over Size 8.1×2.4×3.2m

● Truck Weight 6800kg

● FAW LongV 4×2 Chassis

● Deutz 165hp Engine

● Plastic Tank Material

● Stainless Steel PTO pump (liquid chemical specific )

● Tanker material Optional for High-Strength Steel lined with rubber or Stainless Steel Tanker

● Tank body fabricated from high tensile steel thickness approximately 6-10mm

● Tank inner welded by automatic welding machine

● Tank past air leakage test

● Tank exterior with sand blasting shooting,

● Chemical tank truck features with super loading capacity, excellent stability, driving safely.

● Tank Style optional for elliptical, square round, cylindrical

● Optional for isolated multi compartments for different kinds of liquid chemicals, or liquid drinks /foods

● Bottom rear or top loaded /unloaded form

● Reliable emergency shut-off system

● Roll-over protection system

● Tank Body

The tank body is elliptic cylindrical, round or trapezoidal cylindrical, etc., made of high quality steel plate, The entire tank can be single-chamber or multi-compartment division, There are steel division plates with through holes welded in the tank to strengthen the anti-wave and relieve oil shocks. To prevent corrosion, the outer tank painted rust and decorative paint.

● Tank Manhole Assembly

The manhole is placed on the top of the tank, the material is aluminum or stainless steel, with the functions of breathing and emergency venting. Gas recovery valve, fuel gauge and anti-overflow probe can be mounted on the manhole cover. The built-in breathing valve can keep the internal and outside pressure balance in the process of transportation, and keep sealed at the time of the accident. The emergency venting device will automatically open to release the pressure in the tank in case of accidents and greatly improve the security of oil transportation.

● Tanker Emergency Shut-off valve

Tanker emergency shut-off valve is mounted on the bottom of the tank, has the options of pneumatic manual, aluminum or stainless steel material, Generally pneumatic valve is first chosen. The valve has small internal pressure, flow amount. There are cut-grooves in the flange. When accident occurred, as the cut-groove can’t bear too much momentum, the pipe and tank body will be disconnected automatically. The tank medium can be leak. That makes sure the safety of the tank. To ensure the valve has a good ability to work, what conditions must be met:

1)        When the Emergency Shut-off valve works, the system must ensure the air pressure >0.4 MPa.

2)       The valve body and plunger must keep a high degree of sealing.

3)       The spring must have enough elastic force to reset.

●  PTO

The PTO is mounted on the transmission, there are two types of left and right, the main function is to shift the power of the engine to the pump by drive shaft. For the operation function, please check the PTO instruction manual.

● Pump

There are self-suction centrifugal pump and gear pump. For the performance, please check the instructions.

●  Hoses

Hose connectors use CRJ65 type quick connector, direct butt joint, connector face with a rubber ring seal, easy dismounting and connecting, convenient and reliable. Oil hose assembly is past the conduct inspection, safe and reliable.

●  Ball valve

The tanker output valve adopts ball valve structure. Valve includes seat, seal ring, ball and handle. Turning 90 degree can close or open the valve. The tightness of the ball valve can be adjusted.

●  Four-way ball valve

The control valve is used for the four-way valve. The red dot on the stem indicates that direction is turned off.

●  Antistatic device

(1) Anti-static belt

The ground tape is mounted on the rear of the oil tank and kept in contact with the ground. Its function is transmit the static electricity to the ground which is generated from oil shocks or refueling truck works or tanker truck self-engine works, to prevent fires caused by static electricity.

(2) Anti-static pole

The ground pole is fixed to the frame. When refueling or discharging the oil tank truck, make sure to insert the ground pole in the damp earth to transmit the static electricity to the ground, which generated at the process of refueling and discharging.

TYPICAL COMMODITIES

● Strong Corrosives

● Flammable Liquids

● Oxidizing Liquids

● High-density liquids

● Liquid foods and regular drinks

SPECIAL INSTRUCTION

Chemical liquid transportation in the category of high-dangerous goods transport Although we are familiar with the overview, structural composition and material requirements of chemical liquid transporter through Wikipedia, we rarely know the specific hazards and how to prevent them during normal driving ? Here, we will give you a detailed explanation:

Chemical liquid tank trucks are mainly transport the dangerous, including flammable, flammable, poisonous, corrosive and radioactive. They have certain potential dangers to people's safety. Completing transportation tasks is a technical and professional job. A small careless operation in your regular transportation will led serious losses of property , endanger the environment and people-kills. So we reminder you before you buy the chemical tank truck you should do:

● Your Drivers and Escorts must be qualified to transport dangerous goods;

● Your chemical tank truck should purchase from a quality assured big factories in a safe condition and safe performance;

● Pay attention on the every tiny details when loading the chemicals;

● Drive carefully, smoothly, frequently check on the transport way and choose a proper driving route in a Proper driving time;

● Unload chemical carefully to prevent pollution; An emergency response planning and schedule should be Prepared in your unloading works.

MANUFACTURER BENEFITS

● 20-years tank truck manufacturing experience

● Ease of operation and simple maintenance

● Corrosive resistant parts of tank, no leakage

● 5-years Quality Warranties, No pitting occurs

● Customization available in all style tanks

● Well trained welder, Professional tank engineer

OVERVIEW

CHASSIS

Engine:Model: BF6M2012-16E4 (Manufacturer: China Deutz)

● Diesel, 6-cylinders in line, water cooled, 4 stroke cycles

● Turbocharged intercooling

● Max output power: 165hp (121kw)@2500rpm

● Max torque (N.m/rpm): 590(N.m)@1500 (rpm)

● Displacement (ml): 6060ml

● Emission standard: Euro 4

● Fuel tank capacity: 100 liters

Cab: LONG V Day cab,  flat and reversible cab, strong metal fully welded structure

● Wide view, toughened windscreen, hand-cranked windows.

● Full screen Two (2 No.) wipers.

● Cab-interior is equipped with the followings:

● Short-wave radio

● Mp3 player

● Reading light

● Dashboard with a conventional instrument, speedometer, tachometer, oil pressure gauge, water temperature gauge, fuel gauge etc.

● Horn

Chassis Frame size: 280mm× 80mm× (8+5) mm

● Strong steel constructed frame to be reinforced with cross beam, beams and stringers are connected in the form of riveting with reinforcing steel sheets.

● Tensile strength of frame material Q235A high strength steel.

Transmission model: CA6TBX075M

● Type No.

● Make: FAW Gear Factory

● Floor-mounted manual shift gear lever

● 6 speed forward and 1 speed reverse

● Manufacturer's standard PTO box is provided

● 4x2 RWD truck

Clutch,Steering,Brakes

● Single dry frictional disc, hydraulic boosting.

● Specify diameter Φ350mm

● Power assistance steering

● Left hand driving

● Service brake double circulation air brake system

● Assistant brake engineer exhaust brake

● Park brake potential spring pressing on middle and rear wheels

Axles,Suspension,Wheels, Rims & Tires

● Front axle capacity 6000g

● Rear axle capacity 10000kg

● Leaf spring mechanical suspension

● Front: Heavy duty semi-elliptic metal 7 nos of leaf spring. Double acting telescopic parallel steel shock absorber.

● Rear: Heavy duty semi-elliptic metal leaf spring. 10+3 Second stage helper spring

● Six wheels. Pneumatic tires capable of being driven in snow, muddy roads and off road.

● Manufacturer's standard rims/ tires

● Tire size: 10.00R20, RIDUS tire (ALL WHEELS)

Electric System

● 24 volt system

● Cab interior lighting

● Two headlights minimum, high/ low beam

● Tail/stoplights

● Direction signal lights for front and rear

● Reversing light

● Parking light

● Number plate lights

Backup Equipment & Accessories

● Spare wheel (completely assembled tire and rim) - 1 set, attached to the chassis for transportation and with a separate lock.

● Body color and package

● Final color yellow / white or as customer requested.

● Naked package

Don’t like the above listed truck chassis? No problem! Please scroll down to see our Chassis inventory, you may optional that choose the following different brand of chassis for one of your tanks. There is the one you needs. Or give us a call and we’d build a solution that meet your needs! We Want To Hear From You.

SCROLL DOWN TO PICK UP A SIMILAR CHASSIS

Chose any make or model of truck chassis , supply your own chassis or we can help you select one to fit your needs, popular truck chassis inventory available for purchase brands including ISUZU, HINO, UD, JAC,SINOTRUK,SHACMAN,BEIBEN, DONGFENG.

	FAW Truck  Chassis Collection

	DONGFENG Truck Chassis Collection

	SINOTRUK Truck  Chassis Collection

	FOTON Truck  Chassis Collection

	SHACMAN Truck  Chassis Collection

	JAC Truck  Chassis Collection

	JMC Truck  Chassis Collection

	IVECO  Truck  Chassis Collection

	ISUZU  Truck  Chassis Collection

CHASSIS UPPER BODY

● Capacity of the tank, 12000 liters

● Tank size: 5800(L)×1800(W)×1800(H)

● Material: Q235 steel, or stainless steel / Fiber glass
