Cab Truck FOTON R8 4×4
8 Ton 2-Stage Boom Lift
4 Ton 2-Stage Underlift
5 Ton Worm Gear Winch
CUMMINS Engine ISF2.8s2161P
FEATURES
| CONTROLS | |||
| Dual Side Manual Controls | Standard | ||
| Wired Winch Remote Control | Optional | ||
| Wireless Winch Remote Control | Standard | ||
| BODY | |||
| Lighted Driver Side Toolbox | Optional | ||
| Steel Driver Sidd Toolbox | Standard | ||
| Stainless Steel Rubrails | Optional | ||
| Aluminum Rubrails | Standard | ||
| Aluminum Diamond Plate Decking | Standard | ||
| SUS Diamond Plate Decking | Optional | ||
| Ligted Passenger Side Tool Box | Optional | ||
| Steel Passenger Side Toolbox | Standard | ||
| 24 in. Aluminum Tunnel Box | Optional | ||
| 24 in. Steel Tunnel Box | Optional | ||
| LIGHTING & ELECTRICAL | |||
| DOT Lighting | Standard | ||
| Backup Alarm | Standard | ||
| In-Cab Switch Panel | Optional | ||
| LED Work Lights Upper/Lower | Optional | ||
| LED Lightbar | Standard | ||
| Backup Camera Kit | Optional | ||
| Aluminum Light Pylon | Optional | |||
| BOOM & WINCHES | ||||
| Boom w/ Dual Lift Cylinders | Standard | |||
| Self-loading Wheel Grids | Optional | |||
| Remote Free Spool Handles | Standard | |||
| Single Worm Gear Winch | Optional | |||
| Dual Plantery Winch | Standard | |||
| Dual Worm Gear Winches | Optional | |||
| Tailboard D-Ring | Optional | |||
| High Tensile Steel Material | Standard | |||
| TOWING ACCESSORIES | ||||
| Wheel Lift Tie-Down Straps | Standard | |||
| Fifth Wheel Plate | Optional | |||
| Tow Sling | Optional | |||
| Tow Sling Mounting Brackets | Optional | |||
| Gooseneck Trailer Attachment | Optional | |||
| Spade Foot Attachment | Optional | |||
| Low Angle Recovery Sheave | Optional | |||
| Motorcycle Attachment | Optional | |||
| Steel Dollies( 2nos) | Standard | |||
| Manual L-Arm Wheel Grids | Standard | |||
| Cataphoresis Preimer Painting | Optional | |||
Layout
| Cabin | |||
| Make/Model | FOTON R8 4×4 | ||
| Type | Pick-up Single cab | ||
| Cab Allowed | 1 driver+1 passengers | ||
| Air Condition | YES | ||
| Steering | Right hand Drive | ||
| Centre Lock | YES | ||
| Window | Manual operated | ||
| Driver Seat | Air bag | ||
| Engine | |||
| Make/Model | CUMMINS/ISF2.8s2161P | ||
| Engine System | 4 Cylinders inline, Diesel | ||
| Power/ speed | 120kW(161hp)/3200rpm | ||
| Displacement | 2.776L | ||
| Torque/ Speed | 360Nm/1400-3400rpm | ||
| Fan | Eletric | ||
| Eletric | Cummins | ||
| Clutch | Single Disc, Dry, Diaphragm Spring | ||
| Power Assitance | |||
| Gearbox | JC538 / 5F+1R,Manual | ||
| Steering | Powerd/ RHD | ||
| Brake | Front disc/Rear drum | ||
| RECOVERY BOOM: 2-STAGE | ||||
| Retracted Capacity @ 30° | 16,000 lbs(8000kg) | |||
| Extended Capacity @ 30° | 6,000 lbs.(3000kg) | |||
| Maximum Hook Height | 110 in. (2800mm) | |||
| Maximum Boom Angle | 32° | |||
| REACH PAST TAILBOARD | ||||
| Reach Past Tailboard | 67 in.(1700mm) @ 0° | |||
| Reach Past Tailboard | 46 in (1168mm) @30° | |||
| UNDERLIFT BOOM | ||||
| Retracted Rating | 4,000 lbs(2000kg) | |||
| Retracted Reach | 52 in.(1320mm) | |||
| Extended Rating | 2,000 lbs | |||
| Extended Reach | 81 in(2050mm) | |||
| Positive Tilt | 20° | |||
| Negative Tilt | 20° | |||
| Tow Capacity | 7,500 lbs(3750kg) | |||
| WINCH | ||||
| Winch Capacity | 10,000 lbs.(5000kg) | |||
| Winch Options | Single | |||
| Winch Type | Planetary | |||
| Wire Rope | 3/8 in×110 ft(10mm×30m) | |||
